0.25T Lifting Height 1.5-9m lever chain hoist with 4:1 Safety Factor
Product Details:
Place of Origin: CHINA
Brand Name: SEAGULL
Certification: GS/CE
Model Number: HSH-V
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with steel case for outer packing
Delivery Time: 30 working days after received your payment
Supply Ability: 150000 pcs per year
0.25T Lever Hoist/Lever Block With CE/GS certificate
PRODUCT FEATURES:
Precision Engineering
0.25T SWL capacity with robust 4:1 design factor for superior safety
Crafted with T80-grade alloy chains, ensuring an impressive 8% elongation resistance
Advanced Safety Systems
Revolutionary dual-certified braking system with EN 13157-compliant double-pawl mechanism for exceptional reliability
Durable forged hooks, tested at 150% proof load, guaranteeing maximum safety and durability
Ergonomic Performance
Designed for low-effort operation, requiring just 3.5kg hand pull force even at maximum capacity
Sealed precision bearings expertly crafted to reduce friction loss by an incredible 40%
Industrial-Grade Durability
Precision CNC-machined alloy steel gears with a hardness of HRC 45-50, crafted for durability
Protected with a triple-layer anti-corrosion coating, totaling over 100+μm in thickness, for longevity
Quality Assurance
Rigorous EN 13889:2003 certification with demanding 400% static / 150% dynamic load testing
Meticulously batch-tracked production with MTC certification to assure quality
Global Compliance
CE Marked & GS Certified, complete with comprehensive technical documentation package
Eco-friendly REACH-compliant surface treatment for sustainable usage.
| HSH-V LEVER BLOCKS | |||||||||
| Model | HSH-V2.5 | HSH-V5 | HSH-V7.5 | HSH-V10 | HSH-V15 | HSH-V20 | HSH-V30 | HSH-V60 | HSH-V90 |
| Rated load (T) | 0.25 | 0.5 | 0.75 | 1 | 1.5 | 2 | 3 | 6 | 9 |
| Test load(T) | 0.375 | 0.75 | 1.125 | 1.5 | 2.25 | 3 | 4.5 | 9 | 13.5 |
| Standard lif(m) | 1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Min.distance between two hooks(mm) | 205 | 260 | 295 | 295 | 335 | 385 | 450 | 615 | 720 |
| Efforts required at capacity (N) | 217 | 303 | 140 | 185 | 234 | 251 | 363 | 370 | 375 |
| No.of load chains | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 3 |
| Dlameter of load chain(mm) | 4 | 5 | 6 | 6 | 7.1 | 8 | 10 | 10 | 10 |
| Dimensions(mm) A B C D E | 92 75 205 153 17 | 110 82 260 261 23 | 152 128 295 256 26 | 152 128 295 256 26 | 175 148 335 368 30 | 175 160 385 368 33 | 195 181 450 368 34 | 195 232 615 368 47 | 195 366 720 368 64 |
| Net weight(kg) | 1.85 | 4.6 | 7.7 | 8 | 10.6 | 14.8 | 20 | 28 | 46 |
PACKING:
premier lifting tools and equipment. Our extensive portfolio includes hand chain hoists, lever hoists, electric
hoists, and lifting clamps, all crafted to perfection. Certified with ISO9001:2015 and TUV CE/GS, our products
are synonymous with quality and reliability, serving global markets such as the USA, Germany, and Japan. A
proud OEM partner for leading international brands, we export 95% of our products globally. Our commitment
to advanced testing and stringent quality control ensures unmatched performance. With over half our clientele maintaining
SEAGULL stands as your steadfast partner in delivering innovative and reliable lifting solutions tailored to
your needs.
PRODUCTION EQUIPMENT:
Q1 Manufacturer or Trading Company?
We are Manufacturer and trading company, based in ChangshuCity,Jiangsu Province. Focus: high-quality, safe lifting solutions.
Q2 Certifications?
ISO9001, CE, GS, ASME compliant. Certificates available upon request.
Q3 OEM/ODM?
Yes. Custom colors, logos, manuals,packaging.
Q4 Advantages?
Quality products, wide range, customization, competitive pricing, excellent after-sales service.
Products
Q1 Main Products?
Manual Chain Hoists, Electric Hoists, Electric Trolleys, Beam Trolleys, Beam Clamps, Lifting Clamps, Snatch Blocks, Permanent Magnet Lifters,Mechanical Jacks, Manual Winches, Webbing Slings, etc.
Q2 Manual Chain Hoist Capacity?
0.25 tons - 50 tons. Custom options available.
Q3 Chain Material?
High-strength alloy steel, heat-treated, EN818-7 compliant.
Q4 Electric Hoist Voltage/Control?
220V/380V/415V/440V,50Hz/60Hz. Hand & remote control options.
Q5 Choosing the Right Tool?
Consider load, height, environment, frequency, safety. Contact sales for assistance.
Q6 Product Catalog?
Request via contact form.
Orders&Payment
Q1 MOQ?
Varies. Different products with different MOQ. Please contact us for details.
Q2 Payment Methods?
T/T or L/C in USD/RMB/EUR.
Q3 Delivery Time?
30-60 days, but negotiable for urgent order.
Q4 Trade Terms?
FOB, CIF, CFR, negotiable
After-Sales Service
Q1 Warranty?
1 or 2 years warranty depends on different products, against defects (non-human caused).
Q2 After-Sales Support?
Contact sales representative, email
Q3 Technical Support?
Installation, debugging, maintenance assistance available.
Other
Q1 Samples?
Available on request. Fees may apply.
Q2 Become an Agent?
Contact sales team for details.
